FAG B7013-C-T-P4S-DBM
Fiyatı: 12,679.47 ₺
Özellikler
| Marka | FAG |
| Ürün No | B7013-C-T-P4S-DBM FAG |
| Üretici No | 0380676090000 |
| Alternatif Kodu |
7013CD/P4ADBB |
| EAN | 4012801753999 |
| Kategori | Tek Sıra - Açısal Temaslı |
| Dış (D) MM | 100 |
| En (B) MM | 36 |
| En (B) Inch | 1.4173 |
| Ağırlık | 0.84 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 15 degrees |
| Pairing | DB - O-arrangement, 2 |
| Axial Internal Clearance / Preload | UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DBM | Set Of 2 Bearings O-Arrangement, Medium Preload |
