FAG B7017-E-T-P4S-K5-UM

FAG B7017-E-T-P4S-K5-UM
FAG B7017-E-T-P4S-K5-UM rulman resim 1
FAG B7017-E-T-P4S-K5-UM rulman resim 2
FAG B7017-E-T-P4S-K5-UM rulman resim 3
Fiyatı: 10,394.38 ₺
Özellikler
Marka FAG
Ürün No B7017-E-T-P4S-K5-UM FAG
Üretici No 0388498280000
EAN 4026677971395
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 85
Dış (D) MM 130
En (B) MM 22
İç (d) Inch 3.3465
Dış (D) Inch 5.1181
En (B) Inch 0.8661
Ağırlık 0.88 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik K5 - P4S + K5
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 22
Temel statik yük derecesi, radyal (C 0r) 41500
Limiting speed for grease lubrication (n G Grease) 9500
Limiting speed for oil lubrication (n G Oil) 15000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UM Single Bearing, Universal, Medium Preload
