FAG B7024-E-T-P4S-K5-UL

Fiyatı: 18,508.88 ₺

Özellikler

Ağırlık ve Boyutlar

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	K5 - P4S + K5
Contact Angle	25 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	28
Radial Static Load Rating C0r (N)	78000
Radial Dynamic Load Rating Cr (N)	109000
Temel statik yük derecesi, radyal (C 0r)	"78000.0000"
Limiting speed for grease lubrication (n G Grease)	6700
Limiting speed for oil lubrication (n G Oil)	10000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5	Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL	Single Bearing, Universal, Light Preload
