FAG B7026-E-T-P4S-QUM

Özellikler

Marka	FAG
Ürün No	B7026-E-T-P4S-QUM FAG
Üretici No	0381064420000
EAN	4012801999304
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	130
Dış (D) MM	200
En (B) MM	132
Ağırlık	12.56 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	P4S Hassasiyet (P4ten Yüksek)
Contact Angle	25 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	QM - Quad Set, Medium Preload
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	33
Temel statik yük derecesi, radyal (C 0r)	102000
Limiting speed for grease lubrication (n G Grease)	6000
Limiting speed for oil lubrication (n G Oil)	9500
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
QUM	Set Of 4 Universal Bearings, Medium Preload
