FAG B71905-E-T-P4S-UM

FAG B71905-E-T-P4S-UM
FAG B71905-E-T-P4S-UM rulman resim 1
FAG B71905-E-T-P4S-UM rulman resim 2
FAG B71905-E-T-P4S-UM rulman resim 3
Fiyatı: 2,791.98 ₺
Özellikler
Marka FAG
Ürün No B71905-E-T-P4S-UM FAG
Üretici No 0191536190000
Alternatif Kodu 71905ACDGB/P4A
EAN 4012801454445
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 25
Dış (D) MM 42
En (B) MM 9
İç (d) Inch 0.9843
Dış (D) Inch 1.6535
En (B) Inch 0.3543
Ağırlık 0.04 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 9
Radial Static Load Rating C0r (N) 3600
Radial Dynamic Load Rating Cr (N) 7600
Temel statik yük derecesi, radyal (C 0r) "3600.0000"
Limiting speed for grease lubrication (n G Grease) 32000
Limiting speed for oil lubrication (n G Oil) 50000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearing B719..-E-T-P4S, with steel balls
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
