FAG B71915-E-T-P4S-K5-UL

FAG B71915-E-T-P4S-K5-UL
FAG B71915-E-T-P4S-K5-UL rulman resim 1
FAG B71915-E-T-P4S-K5-UL rulman resim 2
FAG B71915-E-T-P4S-K5-UL rulman resim 3
Fiyatı: 7,967.02 ₺
Özellikler
Marka FAG
Ürün No B71915-E-T-P4S-K5-UL FAG
Üretici No 0384353810000
EAN 4012801456951
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 75
Dış (D) MM 105
En (B) MM 16
İç (d) Inch 2.9528
Dış (D) Inch 4.1339
En (B) Inch 0.6299
Ağırlık 0.35 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik K5 - P4S + K5
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 16
Radial Static Load Rating C0r (N) 22900
Radial Dynamic Load Rating Cr (N) 33000
Temel statik yük derecesi, radyal (C 0r) "22900.0000"
Limiting speed for grease lubrication (n G Grease) 11000
Limiting speed for oil lubrication (n G Oil) 18000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearing B719..-E-T-P4S, with steel balls
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL Single Bearing, Universal, Light Preload
