FAG B71924-E-T-P4S-UL

FAG B71924-E-T-P4S-UL
FAG B71924-E-T-P4S-UL rulman resim 1
FAG B71924-E-T-P4S-UL rulman resim 2
FAG B71924-E-T-P4S-UL rulman resim 3
FAG B71924-E-T-P4S-UL rulman resim 4
FAG B71924-E-T-P4S-UL rulman resim 5
Fiyatı: 19,729.22 ₺
Özellikler
Marka FAG
Ürün No B71924-E-T-P4S-UL FAG
Üretici No 0191551070000
Alternatif Kodu 71924ACDGA/P4A
EAN 4012801458221
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 120
Dış (D) MM 165
En (B) MM 22
İç (d) Inch 4.7244
Dış (D) Inch 6.4961
En (B) Inch 0.8661
Ağırlık 1.16 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 22
Radial Static Load Rating C0r (N) 56000
Radial Dynamic Load Rating Cr (N) 72000
Temel statik yük derecesi, radyal (C 0r) "56000.0000"
Limiting speed for grease lubrication (n G Grease) 7000
Limiting speed for oil lubrication (n G Oil) 11000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearing B719..-E-T-P4S, with steel balls
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
