FAG B7203-C-T-P4S-UM

FAG B7203-C-T-P4S-UM
FAG B7203-C-T-P4S-UM rulman resim 1
FAG B7203-C-T-P4S-UM rulman resim 2
Fiyatı: 2,927.39 ₺
Özellikler
Marka FAG
Ürün No B7203-C-T-P4S-UM FAG
Üretici No 0385375910000
Alternatif Kodu 7203CDGB/P4A
EAN 4026677143624
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 17
Dış (D) MM 40
En (B) MM 12
İç (d) Inch 0.6693
Dış (D) Inch 1.5748
En (B) Inch 0.4724
Ağırlık 0.07 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 12
Temel statik yük derecesi, radyal (C 0r) 5800
Limiting speed for grease lubrication (n G Grease) 38000
Limiting speed for oil lubrication (n G Oil) 56000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
