FAG B7206-C-T-P4S-DUM

Özellikler

Marka	FAG
Ürün No	B7206-C-T-P4S-DUM FAG
Üretici No	0385398530000
Alternatif Kodu	7206CD/P4ADGB
EAN	4026677149091
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	30
Dış (D) MM	62
En (B) MM	32
İç (d) Inch	1.1811
Dış (D) Inch	2.4409
En (B) Inch	1.2598
Ağırlık	0.4 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	P4S Hassasiyet (P4ten Yüksek)
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	DM - 2 Univ Bearings Medium Pre
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	16
Temel statik yük derecesi, radyal (C 0r)	10400
Limiting speed for grease lubrication (n G Grease)	24000
Limiting speed for oil lubrication (n G Oil)	38000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03

Suffix description

C	15° Or 17° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUM	Set Of 2 Universal Bearings, Medium Preload
