FAG B7210-E-T-P4S-K5-UM

FAG B7210-E-T-P4S-K5-UM
FAG B7210-E-T-P4S-K5-UM rulman resim 1
FAG B7210-E-T-P4S-K5-UM rulman resim 2
FAG B7210-E-T-P4S-K5-UM rulman resim 3
Fiyatı: 6,585.28 ₺
Özellikler
Marka FAG
Ürün No B7210-E-T-P4S-K5-UM FAG
Üretici No 0380860850000
EAN 4012801970693
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 50
Dış (D) MM 90
En (B) MM 20
İç (d) Inch 1.9685
Dış (D) Inch 3.5433
En (B) Inch 0.7874
Ağırlık 0.45 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik K5 - P4S + K5
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 20
Temel statik yük derecesi, radyal (C 0r) 21400
Limiting speed for grease lubrication (n G Grease) 14000
Limiting speed for oil lubrication (n G Oil) 22000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UM Single Bearing, Universal, Medium Preload
