FAG B7211-C-T-P4S-UL

FAG B7211-C-T-P4S-UL
FAG B7211-C-T-P4S-UL rulman resim 1
FAG B7211-C-T-P4S-UL rulman resim 2
FAG B7211-C-T-P4S-UL rulman resim 3
FAG B7211-C-T-P4S-UL rulman resim 4
Fiyatı: 5,992.69 ₺
Özellikler
Marka FAG
Ürün No B7211-C-T-P4S-UL FAG
Üretici No 0167276730000
Alternatif Kodu 7211CDGA/P4A
EAN 4012801168168
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 55
Dış (D) MM 100
En (B) MM 21
İç (d) Inch 2.1654
Dış (D) Inch 3.937
En (B) Inch 0.8268
Ağırlık 0.61 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 21
Radial Static Load Rating C0r (N) 26500
Radial Dynamic Load Rating Cr (N) 47000
Temel statik yük derecesi, radyal (C 0r) "26500.0000"
Limiting speed for grease lubrication (n G Grease) 14000
Limiting speed for oil lubrication (n G Oil) 22000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B72..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
