FAG HCB7016-EDLR-T-P4S-UL

FAG HCB7016-EDLR-T-P4S-UL
FAG HCB7016-EDLR-T-P4S-UL rulman resim 1
FAG HCB7016-EDLR-T-P4S-UL rulman resim 2
Fiyatı: 22,352.93 ₺
Özellikler
Marka FAG
Ürün No HCB7016-EDLR-T-P4S-UL FAG
Üretici No 0386230560000
EAN 4026677738493
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 80
Dış (D) MM 125
En (B) MM 22
İç (d) Inch 3.1496
Dış (D) Inch 4.9213
En (B) Inch 0.8661
Ağırlık 0.71 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama DLR
Data from Schaeffler (medias)
Genişlik (b) mm 22
Radial Static Load Rating C0r (N) 37500
Radial Dynamic Load Rating Cr (N) 61000
Temel statik yük derecesi, radyal (C 0r) "37500.0000"
Limiting speed for grease lubrication (n G Grease) 14000
Limiting speed for oil lubrication (n G Oil) 22000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings HCB70..-EDLR, adjusted, matched pairs or sets, contact angle a = 25°, with ceramic balls, restricted tolerances, for direct oil feed via outer ring, with inserted O rings
Suffix description
E 25° Contact Angle
DLR Direct Lube, Integral O-Ring
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
