FAG HCB71930-E-T-P4S-UL-GA21
Fiyatı: 60,669.44 ₺
Özellikler
| Marka | FAG |
| Ürün No | HCB71930-E-T-P4S-UL-GA21 FAG |
| Üretici No | 0591968153821 |
| EAN | 4012802590098 |
| Kategori | Tek Sıra - Açısal Temaslı |
| İç (d) MM | 150 |
| Dış (D) MM | 210 |
| En (B) MM | 28 |
| İç (d) Inch | 5.9055 |
| Dış (D) Inch | 8.2677 |
| En (B) Inch | 1.1024 |
| Ağırlık | 2.1 kg |
| Fok | Kapaksız |
| Kasa Tipi | TB - Sert Fiber Kafes |
| Kesinlik | P4S Hassasiyet (P4ten Yüksek) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama | Standart Yağlama |
| Genişlik (b) mm | 28 |
| Temel statik yük derecesi, radyal (C 0r) | 91000 |
| Limiting speed for grease lubrication (n G Grease) | 7500 |
| Limiting speed for oil lubrication (n G Oil) | 12000 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL | Single Bearing, Universal, Light Preload |
| GA21 | Contains Two Heavy-Duty Greases, L75 And L252, That Are Ideally Suited For Bearings Operating In Machine Tool Spindles |
FAG B71930-E-T-P4S-UL
2.48 kg
150x210x28 mm
FAG B71930E-T-P4S-UL
2.48 kg
150x210x28 mm
FAG B71930-C-T-P4S-UL
2.49 kg
150x210x28 mm
FAG B71930-C-T-P4S-UM
2.49 kg
150x210x28 mm
FAG B71930E-P4
2.48 kg
150x210x28 mm
FAG B71930C-T-P4S-UL
2.49 kg
150x210x28 mm
FAG HCB71930E-T-P4S-UL
2.1 kg
150x210x28 mm
FAG B71930-E-T-P4S-UL-GA21
2.48 kg
150x210x28 mm
FAG B71930-E-T-P4S-UM-GA21
2.48 kg
150x210x28 mm
FAG HCB71930-E-T-P4S-UH
2.04 kg
150x210x28 mm
FAG B71930-E-T-P4S-K5-UL
2.48 kg
150x210x28 mm
FAG B71930E-T-P4S-UM
2.48 kg
150x210x28 mm
FAG Z-508091-01-SKL
2.86 kg
150x210x28 mm
