FAG HCB7207-C-T-P4S-UL

FAG HCB7207-C-T-P4S-UL
FAG HCB7207-C-T-P4S-UL rulman resim 1
FAG HCB7207-C-T-P4S-UL rulman resim 2
FAG HCB7207-C-T-P4S-UL rulman resim 3
FAG HCB7207-C-T-P4S-UL rulman resim 4
Fiyatı: 11,483.26 ₺
Özellikler
Marka FAG
Ürün No HCB7207-C-T-P4S-UL FAG
Üretici No 0380811640000
EAN 4012801759502
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 35
Dış (D) MM 72
En (B) MM 17
İç (d) Inch 1.378
Dış (D) Inch 2.8346
En (B) Inch 0.6693
Ağırlık 0.265 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 17
Radial Static Load Rating C0r (N) 12100
Radial Dynamic Load Rating Cr (N) 25500
Temel statik yük derecesi, radyal (C 0r) "12100.0000"
Limiting speed for grease lubrication (n G Grease) 26000
Limiting speed for oil lubrication (n G Oil) 40000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings HCB72..-C, adjusted, in pairs or sets, contact angle a = 15°, with ceramic balls, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
