FAG HCB7208-C-T-P4S-UL

FAG HCB7208-C-T-P4S-UL
FAG HCB7208-C-T-P4S-UL rulman resim 1
FAG HCB7208-C-T-P4S-UL rulman resim 2
FAG HCB7208-C-T-P4S-UL rulman resim 3
FAG HCB7208-C-T-P4S-UL rulman resim 4
Fiyatı: 10,698.69 ₺
Özellikler
Marka FAG
Ürün No HCB7208-C-T-P4S-UL FAG
Üretici No 0219378420000
EAN 4026677037114
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 40
Dış (D) MM 80
En (B) MM 18
İç (d) Inch 1.5748
Dış (D) Inch 3.1496
En (B) Inch 0.7087
Ağırlık 0.322 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 18
Radial Static Load Rating C0r (N) 15400
Radial Dynamic Load Rating Cr (N) 32500
Temel statik yük derecesi, radyal (C 0r) "15400.0000"
Limiting speed for grease lubrication (n G Grease) 24000
Limiting speed for oil lubrication (n G Oil) 38000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings HCB72..-C, adjusted, in pairs or sets, contact angle a = 15°, with ceramic balls, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
