FAG HSS71920-C-T-P4S-UL

FAG HSS71920-C-T-P4S-UL
FAG HSS71920-C-T-P4S-UL rulman resim 1
FAG HSS71920-C-T-P4S-UL rulman resim 2
FAG HSS71920-C-T-P4S-UL rulman resim 3
Fiyatı: 14,121.74 ₺
Özellikler
Marka FAG
Ürün No HSS71920-C-T-P4S-UL FAG
Üretici No 0384405710000
EAN 4012801491198
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 100
Dış (D) MM 140
En (B) MM 20
İç (d) Inch 3.937
Dış (D) Inch 5.5118
En (B) Inch 0.7874
Ağırlık 0.937 kg
Ürün Özellikleri
Fok 2RU - İki Conta / Temassız Tip
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 20
Temel statik yük derecesi, radyal (C 0r) 23500
Limiting speed for grease lubrication (n G Grease) 13000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
