FAG N1006-D-K-TVP-SP-XL
Fiyatı: 5,498.69 ₺
Özellikler
| Marka | FAG |
| Ürün No | N1006-D-K-TVP-SP-XL FAG |
| Üretici No | 0876044420000 |
| Alternatif Kodu |
N1006-D-K-TVP-SP |
| EAN | 4054371076375 |
| Kategori | Silindirik Makaralı - Tek Sıra |
| İç (d) MM | 30 |
| Dış (D) MM | 55 |
| En (B) MM | 13 |
| İç (d) Inch | 1.1811 |
| Dış (D) Inch | 2.1654 |
| En (B) Inch | 0.5118 |
| Ağırlık | 0.1199 kg |
| Sıkıntı | K - 1:12 Konik Delik (Çoğu Tip İçin Standart) |
| Fok | Kapaksız |
| Kasa Tipi | P - Plastik Kalıplı Kafes |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | Cn Normal İç Oyun |
| Kesinlik | SP - P4Sden Daha Yüksek Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Genişlik (b) mm | 13 |
| Radial Static Load Rating C0r (N) | 15600 |
| Radial Dynamic Load Rating Cr (N) | 17500 |
| Temel statik yük derecesi, radyal (C 0r) | "15600.0000" |
| Fatigue load limit, radial (C ur) | 2270 |
| Limiting speed for grease lubrication (n G Grease) | 21700 |
| Limiting speed for oil lubrication (n G Oil) | 25500 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Super precision cylindrical roller bearings N10..-K-TVP-SP, non-locating bearing, with tapered bore, taper 1:12, separable, with cage |
| D | Bearings With A Modified Internal Construction And The Suffix D Do Not Have A Lubrication Hole Or Lubrication Groove As Standard |
| K | Tapered Bore, Taper 1:12 |
| TVP | Moulded Polyamide Window-Type Cage, Rolling Element Riding |
| SP | Super Precision Specification, Tolerance Class SP, Radial Clearance C1 |
| XL | X-Life |
