FAG NNU4948-S-M-SP-C3
Fiyatı: 89,367.62 ₺
Özellikler
| Marka | FAG |
| Ürün No | NNU4948-S-M-SP-C3 FAG |
| Üretici No | 0192334850030 |
| EAN | 4012801335669 |
| Kategori | Silindirik Makaralı - Çift Sıra |
| İç (d) MM | 240 |
| Dış (D) MM | 320 |
| En (B) MM | 80 |
| İç (d) Inch | 9.4488 |
| Dış (D) Inch | 12.5984 |
| En (B) Inch | 3.1496 |
| Ağırlık | 17.4 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | Kapaksız |
| Kasa Tipi | M - Prinç Kafes |
| Dış Modifikasyon | W33 |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | SP - P4Sden Daha Yüksek Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Genişlik (b) mm | 80 |
| Temel statik yük derecesi, radyal (C 0r) | 1210000 |
| Fatigue load limit, radial (C ur) | 138000 |
| Limiting speed for grease lubrication (n G Grease) | 2400 |
| Limiting speed for oil lubrication (n G Oil) | 2800 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| S | Lubrication Groove And Three Holes In Bearing Outer Ring |
| M | Solid Brass Cage, Roller Guided |
| SP | Special Precision Class For Machine Tool Bearings: Dimensional Accuracy Approximately To P5, Running Accuracy Approximately To P4 |
| C3 | Internal Clearance Larger Than Normal |
