FAG NU1021-XL-MPAX-C3
Fiyatı: 5,971.26 ₺
Özellikler
| Marka | FAG |
| Ürün No | NU1021-XL-MPAX-C3 FAG |
| Üretici No | 0780864770030 |
| Alternatif Kodu |
NU1021-MPAX-C3 |
| EAN | 4054369271676 |
| Kategori | Silindirik Makaralı - Tek Sıra |
| İç (d) MM | 105 |
| Dış (D) MM | 160 |
| En (B) MM | 26 |
| İç (d) Inch | 4.1339 |
| Dış (D) Inch | 6.2992 |
| En (B) Inch | 1.0236 |
| Ağırlık | 1.87 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | Kapaksız |
| Kasa Tipi | MA - Pirinç Kafes, Dış Halkanın Ortasında |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Genişlik (b) mm | 26 |
| Radial Static Load Rating C0r (N) | 154000 |
| Radial Dynamic Load Rating Cr (N) | 132000 |
| Temel statik yük derecesi, radyal (C 0r) | "154000.0000" |
| Hız sınırlaması (n G) | 8400 |
| Referans Hızı (n u03d1r) | 4050 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing NU..-XL-MPAX, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU |
| XL | X-Life |
| MPAX | Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads |
| C3 | Internal Clearance Larger Than Normal |
