FAG NU1040-XL-M1A-J30PC

FAG NU1040-XL-M1A-J30PC
FAG NU1040-XL-M1A-J30PC rulman resim 1
Fiyatı: 32,399.12 ₺
Özellikler
Marka FAG
Ürün No NU1040-XL-M1A-J30PC FAG
Alternatif Kodu NU1040-M1A-J30PC
Kategori Silindirik Makaralı - Tek Sıra
Ağırlık ve Boyutlar
İç (d) MM 200
Dış (D) MM 310
En (B) MM 51
İç (d) Inch 7.874
Dış (D) Inch 12.2047
En (B) Inch 2.0079
Ağırlık 14.6 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Fok Kapaksız
Kasa Tipi MA - Pirinç Kafes, Dış Halkanın Ortasında
Dış Modifikasyon Harici Modifikasyon Yok
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Durotect B Kaplama
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Data from Schaeffler (medias)
Genişlik (b) mm 51
Temel statik yük derecesi, radyal (C 0r) 600000
Hız sınırlaması (n G) 4100
Referans Hızı (n u03d1r) 2310
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
XL X-Life
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
J30PC Rings And Rolling Elements With Black Oxide Coating (Durotect B)
