FAG NU1060-MPAX-J30PC-C3
Fiyatı: 107,364.61 ₺
Özellikler
| Marka | FAG |
| Ürün No | NU1060-MPAX-J30PC-C3 FAG |
| Üretici No | 0725984250030 |
| EAN | 4012802877809 |
| Kategori | Silindirik Makaralı - Tek Sıra |
| İç (d) MM | 300 |
| Dış (D) MM | 460 |
| En (B) MM | 74 |
| İç (d) Inch | 11.811 |
| Dış (D) Inch | 18.1102 |
| En (B) Inch | 2.9134 |
| Ağırlık | 44.4 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | Kapaksız |
| Kasa Tipi | MA - Pirinç Kafes, Dış Halkanın Ortasında |
| Dış Modifikasyon | Harici Modifikasyon Yok |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Durotect B Kaplama |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| MPAX | Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads |
| J30PC | Rings And Rolling Elements With Black Oxide Coating (Durotect B) |
| C3 | Internal Clearance Larger Than Normal |
