FAG NU218-E-XL-N-MPAX-F59-C3
Fiyatı: 11,385.92 ₺
Özellikler
| Marka | FAG |
| Ürün No | NU218-E-XL-N-MPAX-F59-C3 FAG |
| Üretici No | 0852151200030 |
| Alternatif Kodu |
NU218-E-N-MPAX-F59-C3 |
| EAN | 4054369010244 |
| Kategori | Silindirik Makaralı - Tek Sıra |
| İç (d) MM | 90 |
| Dış (D) MM | 160 |
| En (B) MM | 30 |
| İç (d) Inch | 3.5433 |
| Dış (D) Inch | 6.2992 |
| En (B) Inch | 1.1811 |
| Ağırlık | 2.58 kg |
| Sıkıntı | C - Silindirik Delik |
| Fok | Kapaksız |
| Kasa Tipi | MA - Pirinç Kafes, Dış Halkanın Ortasında |
| Dış Modifikasyon | N - Dış Halkada Snap Ring Oluğu |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | A2 - Azaltılmış Genişlik Toleransı |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| E | Increased Load Capacity |
| XL | X-Life |
| N | Snap Ring Groove In The Outer Ring |
| MPAX | Rib-Guided Single-Piece Solid Brass Cage Is A Further Development Of FAG Cage Types MPA And MP1A And Will Replace These Types Successively. It Has Greater Durability With Regard To Shock Loads And Vibrations Than It's Predecessors And It's Especially Well Suited For Applications Involving High Loads |
| F59 | Replaced By |
| H68 | Bearing And Bearing Parts For Voith Getriebe KG, Heidenheim; For Special Cage Design, Width Tolerance, Radial Runout And Bearing Clearance See Specifications |
| C3 | Internal Clearance Larger Than Normal |
