FAG QJ216-XL-N2-MPA-C4
Fiyatı: 6,741.28 ₺
Özellikler
| Marka | FAG |
| Ürün No | QJ216-XL-N2-MPA-C4 FAG |
| Üretici No | 0167423380040 |
| Alternatif Kodu |
QJ216-N2-MPA-C4 |
| EAN | 4012802026474 |
| Kategori | Dört Nokta Temaslı |
| İç (d) MM | 80 |
| Dış (D) MM | 140 |
| En (B) MM | 26 |
| İç (d) Inch | 3.1496 |
| Dış (D) Inch | 5.5118 |
| En (B) Inch | 1.0236 |
| Ağırlık | 1.75 kg |
| Fok | Kapaksız |
| Kasa Tipi | MA - Pirinç Kafes, Dış Halkanın Ortasında |
| Dış Modifikasyon | Dış Halkada N2 - 2 Kilitleme Oluğu |
| Radyal İç Oyun | C4 İç Oyun (C3ten Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Split Inner ring / Outer ring | Split inner ring |
| Genişlik (b) mm | 26 |
| Radial Static Load Rating C0r (N) | 137000 |
| Radial Dynamic Load Rating Cr (N) | 136000 |
| Temel statik yük derecesi, radyal (C 0r) | "137000.0000" |
| Hız sınırlaması (n G) | 9400 |
| Referans Hızı (n u03d1r) | 4250 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Four-point contact bearing QJ2..-XL-N2-MPA, inner ring split |
| XL | X-Life |
| N2 | Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA | Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
| C4 | Bearing Internal Clearance Greater Than C3 |
