FAG 20310-TVP

FAG 20310-TVP
FAG 20310-TVP rulman resim 1
FAG 20310-TVP rulman resim 2
FAG 20310-TVP rulman resim 3
FAG 20310-TVP rulman resim 4
Fiyatı: 6,361.06 ₺
Özellikler
Marka FAG
Ürün No 20310-TVP FAG
Üretici No 0190140900000
EAN 4012801159999
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 50
Dış (D) MM 110
En (B) MM 27
İç (d) Inch 1.9685
Dış (D) Inch 4.3307
En (B) Inch 1.063
Ağırlık 1.21 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W - No Lubrication Groove or Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 27
Radial Static Load Rating C0r (N) 118000
Radial Dynamic Load Rating Cr (N) 108000
Temel statik yük derecesi, radyal (C 0r) "118000.0000"
Hız sınırlaması (n G) 5800
ECLASS number 23-05-09-12
ECLASS2 number 23-05-09-12
Medias description Barrel roller bearings 203, main dimensions to DIN 635-1
Suffix description
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
