FAG 21310-E1-XL-K-C3

FAG 21310-E1-XL-K-C3
FAG 21310-E1-XL-K-C3 rulman resim 1
FAG 21310-E1-XL-K-C3 rulman resim 2
FAG 21310-E1-XL-K-C3 rulman resim 3
FAG 21310-E1-XL-K-C3 rulman resim 4
FAG 21310-E1-XL-K-C3 rulman resim 5
Fiyatı: 1,653.39 ₺
Özellikler
Marka FAG
Ürün No 21310-E1-XL-K-C3 FAG
Üretici No 0219425440030
Alternatif Kodu 21310-E1-K-C3
EAN 4026677959614
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 50
Dış (D) MM 110
En (B) MM 27
İç (d) Inch 1.9685
Dış (D) Inch 4.3307
En (B) Inch 1.063
Ağırlık 1.323 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 27
Radial Static Load Rating C0r (N) 130000
Radial Dynamic Load Rating Cr (N) 129000
Temel statik yük derecesi, radyal (C 0r) "130000.0000"
Hız sınırlaması (n G) 9000
Referans Hızı (n u03d1r) 5400
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
C3 Internal Clearance Larger Than Normal
