FAG 20311-TVP

FAG 20311-TVP
FAG 20311-TVP rulman resim 1
FAG 20311-TVP rulman resim 2
FAG 20311-TVP rulman resim 3
FAG 20311-TVP rulman resim 4
Fiyatı: 7,020.21 ₺
Özellikler
Marka FAG
Ürün No 20311-TVP FAG
Üretici No 0167021310000
EAN 4012801286893
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 55
Dış (D) MM 120
En (B) MM 29
İç (d) Inch 2.1654
Dış (D) Inch 4.7244
En (B) Inch 1.1417
Ağırlık 1.57 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W - No Lubrication Groove or Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 29
Radial Static Load Rating C0r (N) 138000
Radial Dynamic Load Rating Cr (N) 120000
Temel statik yük derecesi, radyal (C 0r) "138000.0000"
Hız sınırlaması (n G) 5400
ECLASS number 23-05-09-12
ECLASS2 number 23-05-09-12
Medias description Barrel roller bearings 203, main dimensions to DIN 635-1
Suffix description
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
