FAG 21311-E1-XL

FAG 21311-E1-XL
FAG 21311-E1-XL rulman resim 1
FAG 21311-E1-XL rulman resim 2
FAG 21311-E1-XL rulman resim 3
FAG 21311-E1-XL rulman resim 4
FAG 21311-E1-XL rulman resim 5
FAG 21311-E1-XL rulman resim 6
Fiyatı: 1,933.57 ₺
Özellikler
Marka FAG
Ürün No 21311-E1-XL FAG
Üretici No 0190146270000
Alternatif Kodu 21311-E1
EAN 4026677904638
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 55
Dış (D) MM 120
En (B) MM 29
İç (d) Inch 2.1654
Dış (D) Inch 4.7244
En (B) Inch 1.1417
Ağırlık 1.276 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 29
Radial Static Load Rating C0r (N) 155000
Radial Dynamic Load Rating Cr (N) 160000
Temel statik yük derecesi, radyal (C 0r) "155000.0000"
Hız sınırlaması (n G) 8100
Referans Hızı (n u03d1r) 5100
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
