FAG 20312-TVP

FAG 20312-TVP
FAG 20312-TVP rulman resim 1
FAG 20312-TVP rulman resim 2
FAG 20312-TVP rulman resim 3
FAG 20312-TVP rulman resim 4
Fiyatı: 6,955.94 ₺
Özellikler
Marka FAG
Ürün No 20312-TVP FAG
Üretici No 0167021400000
EAN 4012801185929
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 60
Dış (D) MM 130
En (B) MM 31
İç (d) Inch 2.3622
Dış (D) Inch 5.1181
En (B) Inch 1.2205
Ağırlık 1.96 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W - No Lubrication Groove or Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 31
Radial Static Load Rating C0r (N) 171000
Radial Dynamic Load Rating Cr (N) 147000
Temel statik yük derecesi, radyal (C 0r) "171000.0000"
Hız sınırlaması (n G) 4950
ECLASS number 23-05-09-12
ECLASS2 number 23-05-09-12
Medias description Barrel roller bearings 203, main dimensions to DIN 635-1
Suffix description
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
