FAG 21312-E1-XL

FAG 21312-E1-XL
FAG 21312-E1-XL rulman resim 1
FAG 21312-E1-XL rulman resim 2
FAG 21312-E1-XL rulman resim 3
FAG 21312-E1-XL rulman resim 4
FAG 21312-E1-XL rulman resim 5
FAG 21312-E1-XL rulman resim 6
FAG 21312-E1-XL rulman resim 7
Fiyatı: 2,195.65 ₺
Özellikler
Marka FAG
Ürün No 21312-E1-XL FAG
Üretici No 0190146430000
Alternatif Kodu 21312-E1
EAN 4026677904645
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 60
Dış (D) MM 130
En (B) MM 31
İç (d) Inch 2.3622
Dış (D) Inch 5.1181
En (B) Inch 1.2205
Ağırlık 1.886 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 31
Radial Static Load Rating C0r (N) 226000
Radial Dynamic Load Rating Cr (N) 211000
Temel statik yük derecesi, radyal (C 0r) "226000.0000"
Hız sınırlaması (n G) 6700
Referans Hızı (n u03d1r) 4100
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
