FAG 20313-MB-C3

FAG 20313-MB-C3
FAG 20313-MB-C3 rulman resim 1
FAG 20313-MB-C3 rulman resim 2
FAG 20313-MB-C3 rulman resim 3
Fiyatı: 7,825.58 ₺
Özellikler
Marka FAG
Ürün No 20313-MB-C3 FAG
Üretici No 0190141710030
EAN 4012801286985
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 65
Dış (D) MM 140
En (B) MM 33
İç (d) Inch 2.5591
Dış (D) Inch 5.5118
En (B) Inch 1.2992
Ağırlık 2.61 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W - No Lubrication Groove or Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 33
Radial Static Load Rating C0r (N) 195000
Radial Dynamic Load Rating Cr (N) 168000
Temel statik yük derecesi, radyal (C 0r) "195000.0000"
Hız sınırlaması (n G) 4700
ECLASS number 23-05-09-12
ECLASS2 number 23-05-09-12
Medias description Barrel roller bearings 203, main dimensions to DIN 635-1
Suffix description
MB Solid Brass Cage, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
