FAG 21313-E1-XL

FAG 21313-E1-XL
FAG 21313-E1-XL rulman resim 1
FAG 21313-E1-XL rulman resim 2
FAG 21313-E1-XL rulman resim 3
FAG 21313-E1-XL rulman resim 4
FAG 21313-E1-XL rulman resim 5
Fiyatı: 2,851.26 ₺
Özellikler
Marka FAG
Ürün No 21313-E1-XL FAG
Üretici No 0219426090000
Alternatif Kodu 21313-E1
EAN 4026677959850
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 65
Dış (D) MM 140
En (B) MM 33
İç (d) Inch 2.5591
Dış (D) Inch 5.5118
En (B) Inch 1.2992
Ağırlık 2.126 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 33
Radial Static Load Rating C0r (N) 270000
Radial Dynamic Load Rating Cr (N) 250000
Temel statik yük derecesi, radyal (C 0r) "270000.0000"
Hız sınırlaması (n G) 6200
Referans Hızı (n u03d1r) 3600
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 213..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
