FAG 22205-E1-XL-C2

FAG 22205-E1-XL-C2
FAG 22205-E1-XL-C2 rulman resim 1
FAG 22205-E1-XL-C2 rulman resim 2
FAG 22205-E1-XL-C2 rulman resim 3
FAG 22205-E1-XL-C2 rulman resim 4
FAG 22205-E1-XL-C2 rulman resim 5
FAG 22205-E1-XL-C2 rulman resim 6
Fiyatı: 1,316.02 ₺
Özellikler
Marka FAG
Ürün No 22205-E1-XL-C2 FAG
Üretici No 0167032510020
Alternatif Kodu 22205-E1-C2
EAN 4026677807991
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 25
Dış (D) MM 52
En (B) MM 18
İç (d) Inch 0.9843
Dış (D) Inch 2.0472
En (B) Inch 0.7087
Ağırlık 0.18 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C2 İç Oyun (Cnden Az)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 18
Radial Static Load Rating C0r (N) 42500
Radial Dynamic Load Rating Cr (N) 48500
Temel statik yük derecesi, radyal (C 0r) "42500.0000"
Hız sınırlaması (n G) 14400
Referans Hızı (n u03d1r) 9200
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
C2 Bearing Internal Clearance Smaller Than Normal
