FAG 22205E1K-C3
Fiyatı: 1,090.34 ₺
Özellikler
| Marka | FAG |
| Ürün No | 22205E1K.C3 FAG |
| Kategori | Küresel Makaralı |
| İç (d) MM | 25 |
| Dış (D) MM | 52 |
| En (B) MM | 18 |
| İç (d) Inch | 0.9843 |
| Dış (D) Inch | 2.0472 |
| En (B) Inch | 0.7087 |
| Ağırlık | 0.164 kg |
| Sıkıntı | K - 1:12 Konik Delik (Çoğu Tip İçin Standart) |
| Yağlama Enhancement | W33 - Lubrication Groove and 3 Holes |
| Fok | Kapaksız |
| Kasa Tipi | S - Çelik veya Standart Kafes |
| Radyal İç Oyun | C3 İç Oyun (Cnden Yüksek) |
| Kesinlik | Standart Hassasiyet |
| Isı Sabitleme | Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| E1 | Increased Capacity Design |
| K | Tapered Bore, Taper 1:12 |
| C3 | Internal Clearance Larger Than Normal |
FAG 22205-E1-XL-K-C3
0.164 kg
25x52x18 mm
FAG 22205-E1-XL-K
0.164 kg
25x52x18 mm
FAG 22205-E1-XL-C3
0.155 kg
25x52x18 mm
FAG 22205-E1-XL
0.155 kg
25x52x18 mm
FAG 22205E1K
0.164 kg
25x52x18 mm
FAG 22205-E1-XL-C2
0.18 kg
25x52x18 mm
FAG 22205HLK-MB
0.175 kg
25x52x18 mm
FAG 22205E1-C3
0.155 kg
25x52x18 mm
FAG 22205ESK-TVPB
0.175 kg
25x52x18 mm
FAG 22205ES-TVPB
0.155 kg
25x52x18 mm
FAG 22205ESK-TVPB-C3
0.175 kg
25x52x18 mm
FAG 22205EK
0.164 kg
25x52x18 mm
FAG 22205ES-TVPB-C3
0.155 kg
25x52x18 mm
FAG 22205E-C3
0.155 kg
25x52x18 mm
FAG 22205E-TVPB
0.155 kg
25x52x18 mm
FAG 22205ESK-C3
0.164 kg
25x52x18 mm
FAG 22205-E1-XL-TVPB-C3
0.155 kg
25x52x18 mm
FAG 22205-E1-K-C3
0.164 kg
25x52x18 mm
FAG 22205EK-TVPB
0.175 kg
25x52x18 mm
FAG 22205-E1-K
0.164 kg
25x52x18 mm
FAG 22205E1
0.155 kg
25x52x18 mm
FAG 22205-E1
0.155 kg
25x52x18 mm
FAG 22205EK-C3
0.164 kg
25x52x18 mm
FAG 22205EASK-M-C3
0.26 kg
25x52x18 mm
FAG 22205HL-MB
0.186 kg
25x52x18 mm
FAG 22205ES
0.155 kg
25x52x18 mm
FAG 22205-E1-C2
0.18 kg
25x52x18 mm
FAG 22205-E1-C4
0.155 kg
25x52x18 mm
