FAG 22210-E1-XL-K-C4

FAG 22210-E1-XL-K-C4
FAG 22210-E1-XL-K-C4 rulman resim 1
FAG 22210-E1-XL-K-C4 rulman resim 2
FAG 22210-E1-XL-K-C4 rulman resim 3
Fiyatı: 1,486.99 ₺
Özellikler
Marka FAG
Ürün No 22210-E1-XL-K-C4 FAG
Üretici No 0167035450040
Alternatif Kodu 22210-E1-K-C4
EAN 4026677941701
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 50
Dış (D) MM 90
En (B) MM 23
İç (d) Inch 1.9685
Dış (D) Inch 3.5433
En (B) Inch 0.9055
Ağırlık 0.579 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C4 İç Oyun (C3ten Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 23
Radial Static Load Rating C0r (N) 107000
Radial Dynamic Load Rating Cr (N) 109000
Temel statik yük derecesi, radyal (C 0r) "107000.0000"
Hız sınırlaması (n G) 9800
Referans Hızı (n u03d1r) 5100
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
C4 Bearing Internal Clearance Greater Than C3
