FAG 22226-E1-XL

FAG 22226-E1-XL
FAG 22226-E1-XL rulman resim 1
FAG 22226-E1-XL rulman resim 2
FAG 22226-E1-XL rulman resim 3
FAG 22226-E1-XL rulman resim 4
FAG 22226-E1-XL rulman resim 5
FAG 22226-E1-XL rulman resim 6
FAG 22226-E1-XL rulman resim 7
Fiyatı: 8,204.77 ₺
Özellikler
Marka FAG
Ürün No 22226-E1-XL FAG
Üretici No 0190004990000
Alternatif Kodu 22226-E1
EAN 4026677827302
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 130
Dış (D) MM 230
En (B) MM 64
İç (d) Inch 5.1181
Dış (D) Inch 9.0551
En (B) Inch 2.5197
Ağırlık 10.5 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 64
Radial Static Load Rating C0r (N) 890000
Radial Dynamic Load Rating Cr (N) 760000
Temel statik yük derecesi, radyal (C 0r) "890000.0000"
Hız sınırlaması (n G) 3350
Referans Hızı (n u03d1r) 2500
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 222..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
