FAG 22226-E1A-XL-MA-T41A

FAG 22226-E1A-XL-MA-T41A
FAG 22226-E1A-XL-MA-T41A rulman resim 1
FAG 22226-E1A-XL-MA-T41A rulman resim 2
FAG 22226-E1A-XL-MA-T41A rulman resim 3
FAG 22226-E1A-XL-MA-T41A rulman resim 4
FAG 22226-E1A-XL-MA-T41A rulman resim 5
Fiyatı: 20,650.66 ₺
Özellikler
Marka FAG
Ürün No 22226-E1A-XL-MA-T41A FAG
Üretici No 0386678860000
EAN 4026677859624
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 130
Dış (D) MM 230
En (B) MM 64
İç (d) Inch 5.1181
Dış (D) Inch 9.0551
En (B) Inch 2.5197
Ağırlık 11 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi MA - Pirinç Kafes, Dış Halkanın Ortasında
Radyal İç Oyun C4 İç Oyun (C3ten Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 64
Temel statik yük derecesi, radyal (C 0r) 890000
Hız sınırlaması (n G) 3350
Referans Hızı (n u03d1r) 2500
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
MA Machined Brass Cage, Outer Ring Guided
T41A Spherical Roller Bearings For Vibrating Screens (C4 Clearance), Old Designation is C4.F80
