FAG 22312-E1-XL-TVPB-C3

FAG 22312-E1-XL-TVPB-C3
FAG 22312-E1-XL-TVPB-C3 rulman resim 1
FAG 22312-E1-XL-TVPB-C3 rulman resim 2
FAG 22312-E1-XL-TVPB-C3 rulman resim 3
FAG 22312-E1-XL-TVPB-C3 rulman resim 4
FAG 22312-E1-XL-TVPB-C3 rulman resim 5
Fiyatı: 2,931.55 ₺
Özellikler
Marka FAG
Ürün No 22312-E1-XL-TVPB-C3 FAG
Üretici No 0389123760030
Alternatif Kodu 22312-E1-TVPB-C3
EAN 4026677807830
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 60
Dış (D) MM 130
En (B) MM 46
İç (d) Inch 2.3622
Dış (D) Inch 5.1181
En (B) Inch 1.811
Ağırlık 2.8 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
