FAG 22315-E1-K-C3

FAG 22315-E1-K-C3
FAG 22315-E1-K-C3 rulman resim 1
FAG 22315-E1-K-C3 rulman resim 2
FAG 22315-E1-K-C3 rulman resim 3
FAG 22315-E1-K-C3 rulman resim 4
Fiyatı: 4,467.63 ₺
Özellikler
Marka FAG
Ürün No 22315-E1-K-C3 FAG
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 75
Dış (D) MM 160
En (B) MM 55
İç (d) Inch 2.9528
Dış (D) Inch 6.2992
En (B) Inch 2.1654
Ağırlık 4.85 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi S - Çelik veya Standart Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Suffix description
E1 Increased Capacity Design
K Tapered Bore, Taper 1:12
C3 Internal Clearance Larger Than Normal
