FAG 22315-E1A-XL-M

FAG 22315-E1A-XL-M
FAG 22315-E1A-XL-M rulman resim 1
FAG 22315-E1A-XL-M rulman resim 2
FAG 22315-E1A-XL-M rulman resim 3
FAG 22315-E1A-XL-M rulman resim 4
FAG 22315-E1A-XL-M rulman resim 5
FAG 22315-E1A-XL-M rulman resim 6
Fiyatı: 6,156.38 ₺
Özellikler
Marka FAG
Ürün No 22315-E1A-XL-M FAG
Üretici No 0190203090000
Alternatif Kodu 22315-E1A-M
EAN 4026677847980
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 75
Dış (D) MM 160
En (B) MM 55
İç (d) Inch 2.9528
Dış (D) Inch 6.2992
En (B) Inch 2.1654
Ağırlık 5.21 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 55
Radial Static Load Rating C0r (N) 450000
Radial Dynamic Load Rating Cr (N) 445000
Temel statik yük derecesi, radyal (C 0r) "450000.0000"
Hız sınırlaması (n G) 4500
Referans Hızı (n u03d1r) 3550
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearing 223..-E1A-XL-M, symmetric 2 outer ribs
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
M Solid Brass Cage, Guided By Rollers
