FAG 23028-E1A-XL-K-M-C4

FAG 23028-E1A-XL-K-M-C4
FAG 23028-E1A-XL-K-M-C4 rulman resim 1
FAG 23028-E1A-XL-K-M-C4 rulman resim 2
FAG 23028-E1A-XL-K-M-C4 rulman resim 3
FAG 23028-E1A-XL-K-M-C4 rulman resim 4
Fiyatı: 8,806.72 ₺
Özellikler
Marka FAG
Ürün No 23028-E1A-XL-K-M-C4 FAG
Üretici No 0190249590040
Alternatif Kodu 23028-E1A-K-M-C4
EAN 4026677871466
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 140
Dış (D) MM 210
En (B) MM 53
İç (d) Inch 5.5118
Dış (D) Inch 8.2677
En (B) Inch 2.0866
Ağırlık 6.1 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun C4 İç Oyun (C3ten Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 53
Radial Static Load Rating C0r (N) 800000
Radial Dynamic Load Rating Cr (N) 570000
Temel statik yük derecesi, radyal (C 0r) "800000.0000"
Hız sınırlaması (n G) 3450
Referans Hızı (n u03d1r) 2390
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 230..-E1A-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
K Tapered Bore, Taper 1:12
M Solid Brass Cage, Guided By Rollers
C4 Bearing Internal Clearance Greater Than C3
