FAG 23028-E1A-XL-M-C3

FAG 23028-E1A-XL-M-C3
FAG 23028-E1A-XL-M-C3 rulman resim 1
FAG 23028-E1A-XL-M-C3 rulman resim 2
FAG 23028-E1A-XL-M-C3 rulman resim 3
FAG 23028-E1A-XL-M-C3 rulman resim 4
FAG 23028-E1A-XL-M-C3 rulman resim 5
Fiyatı: 8,177.73 ₺
Özellikler
Marka FAG
Ürün No 23028-E1A-XL-M-C3 FAG
Üretici No 0190010530030
Alternatif Kodu 23028-E1A-M-C3
EAN 4026677827722
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 140
Dış (D) MM 210
En (B) MM 53
İç (d) Inch 5.5118
Dış (D) Inch 8.2677
En (B) Inch 2.0866
Ağırlık 6.27 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 53
Radial Static Load Rating C0r (N) 800000
Radial Dynamic Load Rating Cr (N) 570000
Temel statik yük derecesi, radyal (C 0r) "800000.0000"
Hız sınırlaması (n G) 3450
Referans Hızı (n u03d1r) 2390
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 230..-E1A, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
M Solid Brass Cage, Guided By Rollers
C3 Internal Clearance Larger Than Normal
