FAG 23030-E1-K-TVPB

FAG 23030-E1-K-TVPB
FAG 23030-E1-K-TVPB rulman resim 1
FAG 23030-E1-K-TVPB rulman resim 2
FAG 23030-E1-K-TVPB rulman resim 3
FAG 23030-E1-K-TVPB rulman resim 4
Fiyatı: 8,801.10 ₺
Özellikler
Marka FAG
Ürün No 23030-E1-K-TVPB FAG
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 150
Dış (D) MM 225
En (B) MM 56
İç (d) Inch 5.9055
Dış (D) Inch 8.8583
En (B) Inch 2.2047
Ağırlık 7 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Suffix description
E1 Increased Capacity Design
K Tapered Bore, Taper 1:12
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
