FAG 23030-E1-K-TVPB-C3 rulman resim 1
FAG 23030-E1-K-TVPB-C3 rulman resim 2
FAG 23030-E1-K-TVPB-C3 rulman resim 3
FAG 23030-E1-K-TVPB-C3 rulman resim 4
FAG RULMAN
Sipariş ve iletişim bilgilerimiz.
Merkez: Başakşehir Sanayi Sitesi, İkitelli Organize Sanayi Bölgesi No:36/37/38 / İstanbul
Depo 1: Hadımköy Depo Alanı, Havalanı Yolu NO:22 Arnavutköy / İstanbul
0850 840 8255
info@fagrulman.net
0(533) 472 5913
TOPTANCI PANELİ GİRİŞİ
B2B toptancı paneli hesabınız yoksa, Yeni üyelik için WhatsApp üzerinden iletişime geçiniz.
B2B PANEL GİRİŞİ
FAG 23030-E1-K-TVPB-C3
Fiyatı: 9,778.91 ₺
Özellikler
Marka FAG
Ürün No 23030-E1-K-TVPB-C3 FAG
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 150
Dış (D) MM 225
En (B) MM 56
İç (d) Inch 5.9055
Dış (D) Inch 8.8583
En (B) Inch 2.2047
Ağırlık 7 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi P - Plastik Kalıplı Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Suffix description
E1 Increased Capacity Design
K Tapered Bore, Taper 1:12
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C3 Internal Clearance Larger Than Normal
