FAG 23122-E1A-K-M

FAG 23122-E1A-K-M
FAG 23122-E1A-K-M rulman resim 1
FAG 23122-E1A-K-M rulman resim 2
Fiyatı: 6,706.75 ₺
Özellikler
Marka FAG
Ürün No 23122-E1A-K-M FAG
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 110
Dış (D) MM 180
En (B) MM 56
İç (d) Inch 4.3307
Dış (D) Inch 7.0866
En (B) Inch 2.2047
Ağırlık 5.4 kg
Ürün Özellikleri
Sıkıntı K - 1:12 Konik Delik (Çoğu Tip İçin Standart)
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun Cn Normal İç Oyun
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
K Tapered Bore, Taper 1:12
M Solid Brass Cage, Guided By Rollers
