FAG 23122-E1A-XL-M-C3

FAG 23122-E1A-XL-M-C3
FAG 23122-E1A-XL-M-C3 rulman resim 1
FAG 23122-E1A-XL-M-C3 rulman resim 2
FAG 23122-E1A-XL-M-C3 rulman resim 3
FAG 23122-E1A-XL-M-C3 rulman resim 4
FAG 23122-E1A-XL-M-C3 rulman resim 5
FAG 23122-E1A-XL-M-C3 rulman resim 6
FAG 23122-E1A-XL-M-C3 rulman resim 7
FAG 23122-E1A-XL-M-C3 rulman resim 8
Fiyatı: 6,706.75 ₺
Özellikler
Marka FAG
Ürün No 23122-E1A-XL-M-C3 FAG
Üretici No 0190304600030
Alternatif Kodu 23122-E1A-M-C3
EAN 4026677828170
Kategori Küresel Makaralı
Ağırlık ve Boyutlar
İç (d) MM 110
Dış (D) MM 180
En (B) MM 56
İç (d) Inch 4.3307
Dış (D) Inch 7.0866
En (B) Inch 2.2047
Ağırlık 5.51 kg
Ürün Özellikleri
Sıkıntı C - Silindirik Delik
Yağlama Enhancement W33 - Lubrication Groove and 3 Holes
Fok Kapaksız
Kasa Tipi M - Prinç Kafes
Radyal İç Oyun C3 İç Oyun (Cnden Yüksek)
Kesinlik Standart Hassasiyet
Isı Sabitleme Isı Stabilizasyonu Yok - 120 °Cye kadar sıcaklıklar
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Genişlik (b) mm 56
Radial Static Load Rating C0r (N) 680000
Radial Dynamic Load Rating Cr (N) 530000
Temel statik yük derecesi, radyal (C 0r) "680000.0000"
Hız sınırlaması (n G) 3700
Referans Hızı (n u03d1r) 2550
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 231..-E1A, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
A Modified Internal Construction
XL X-Life
M Solid Brass Cage, Guided By Rollers
C3 Internal Clearance Larger Than Normal
