FAG 7209-B-XL-MP-P6-UA Resim 4
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 2,242.86 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
45 |
| Dış (D) MM |
85 |
| En (B) MM |
19 |
| İç (d) Inch |
1.7717 |
| Dış (D) Inch |
3.3465 |
| En (B) Inch |
0.748 |
| Ağırlık |
0.43 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Kasa Tipi |
M - Prinç Kafes |
| Kesinlik |
P6 Hassasiyeti (Standarttan Yüksek) |
| Contact Angle |
40 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Yağlama |
Standart Yağlama |
Data from Schaeffler (medias)
| Radial Static Load Rating C0r (N) |
27000 |
| Radial Dynamic Load Rating Cr (N) |
40000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
Suffix description
| B |
40° Contact Angle |
| XL |
X-Life |
| MP |
Machined Brass Cage, Window Type, Rolling Element Riding |
| P6 |
Dimensional And Running Accuracy To ISO Tolerance Class 6 (Better Than Normal) |
| UA |
Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
