FAG B7003-C-2RSD-T-P4S-UL

FAG B7003-C-2RSD-T-P4S-UL
FAG B7003-C-2RSD-T-P4S-UL rulman resim 1
FAG B7003-C-2RSD-T-P4S-UL rulman resim 2
FAG B7003-C-2RSD-T-P4S-UL rulman resim 3
Fiyatı: 3,019.95 ₺
Özellikler
Marka FAG
Ürün No B7003-C-2RSD-T-P4S-UL FAG
Üretici No 0191499130000
EAN 4026677498625
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 17
Dış (D) MM 35
En (B) MM 10
İç (d) Inch 0.6693
Dış (D) Inch 1.378
En (B) Inch 0.3937
Ağırlık 0.04 kg
Ürün Özellikleri
Fok 2RU - İki Conta / Temassız Tip
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 10
Radial Static Load Rating C0r (N) 3500
Radial Dynamic Load Rating Cr (N) 8600
Temel statik yük derecesi, radyal (C 0r) "3500.0000"
Limiting speed for grease lubrication (n G Grease) 45000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-C-2RSD, adjusted, in pairs or sets, contact angle a = 15°, lip seals on both sides, non-contact, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
2RSD Lip Seals On Both Sides, Non-Contact
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
