FAG B7003-E-T-P4S-UL

FAG B7003-E-T-P4S-UL
FAG B7003-E-T-P4S-UL rulman resim 1
FAG B7003-E-T-P4S-UL rulman resim 2
FAG B7003-E-T-P4S-UL rulman resim 3
FAG RULMAN
Sipariş ve iletişim bilgilerimiz.
Merkez: Başakşehir Sanayi Sitesi, İkitelli Organize Sanayi Bölgesi No:36/37/38 / İstanbul
Depo 1: Hadımköy Depo Alanı, Havalanı Yolu NO:22 Arnavutköy / İstanbul
0850 840 8255
info@fagrulman.net
0(533) 472 5913
TOPTANCI PANELİ GİRİŞİ
B2B toptancı paneli hesabınız yoksa, Yeni üyelik için WhatsApp üzerinden iletişime geçiniz.
B2B PANEL GİRİŞİ
FAG B7003-E-T-P4S-UL
Fiyatı: 2,589.60 ₺
Özellikler
Marka FAG
Ürün No B7003-E-T-P4S-UL FAG
Üretici No 0191500080000
Alternatif Kodu 7003ACDGA/P4A
EAN 4012801445603
Kategori Tek Sıra - Açısal Temaslı
Ağırlık ve Boyutlar
İç (d) MM 17
Dış (D) MM 35
En (B) MM 10
İç (d) Inch 0.6693
Dış (D) Inch 1.378
En (B) Inch 0.3937
Ağırlık 0.04 kg
Ürün Özellikleri
Fok Kapaksız
Kasa Tipi TB - Sert Fiber Kafes
Kesinlik P4S Hassasiyet (P4ten Yüksek)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama Standart Yağlama
Data from Schaeffler (medias)
Genişlik (b) mm 10
Radial Static Load Rating C0r (N) 3350
Radial Dynamic Load Rating Cr (N) 8200
Temel statik yük derecesi, radyal (C 0r) "3350.0000"
Limiting speed for grease lubrication (n G Grease) 43000
Limiting speed for oil lubrication (n G Oil) 63000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
