FAG B7012-E-T-P4S-K5-UL-J15F Resim 3
Ürüne ait görsel ürün fotoğrafı ve resmi.
Fiyatı: 6,738.37 ₺
Özellikler
Ağırlık ve Boyutlar
| İç (d) MM |
60 |
| Dış (D) MM |
95 |
| En (B) MM |
18 |
| İç (d) Inch |
2.3622 |
| Dış (D) Inch |
3.7402 |
| En (B) Inch |
0.7087 |
| Ağırlık |
0.4 kg
|
Ürün Özellikleri
| Fok |
Kapaksız |
| Kasa Tipi |
TB - Sert Fiber Kafes |
| Kesinlik |
K5 - P4S + K5 |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Yağlama |
Standart Yağlama |
Data from Schaeffler (medias)
| Genişlik (b) mm |
18 |
| Temel statik yük derecesi, radyal (C 0r) |
22600 |
| Limiting speed for grease lubrication (n G Grease) |
13000 |
| Limiting speed for oil lubrication (n G Oil) |
20000 |
Suffix description
| E |
25° Contact Angle |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 |
Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL |
Single Bearing, Universal, Light Preload |
| J15F |
Marking Specifications Of Measured Values |
