FAG B7017-E-T-P4S-TBTL

Özellikler

Marka	FAG
Ürün No	B7017-E-T-P4S-TBTL FAG
Üretici No	0191520510000
EAN	4012801451512
Kategori	Tek Sıra - Açısal Temaslı

Ağırlık ve Boyutlar

İç (d) MM	85
Dış (D) MM	130
En (B) MM	66
İç (d) Inch	3.3465
Dış (D) Inch	5.1181
En (B) Inch	2.5984
Ağırlık	2.64 kg

Ürün Özellikleri

Fok	Kapaksız
Kasa Tipi	TB - Sert Fiber Kafes
Kesinlik	P4S Hassasiyet (P4ten Yüksek)
Contact Angle	25 degrees
Pairing	TBT - O- and Tandem Arrangement, 3
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Yağlama	Standart Yağlama

Data from Schaeffler (medias)

Genişlik (b) mm	22
Temel statik yük derecesi, radyal (C 0r)	41500
Limiting speed for grease lubrication (n G Grease)	9500
Limiting speed for oil lubrication (n G Oil)	15000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
TBTL	Set Of 3 Bearings Tandem u2013 O-Arrangement, Light Preload
